How to Dual Boot Windows 10 and Arch Linux Safely (2025 Updated Guide)

If you love Windows 10 but also want the power and flexibility of Arch Linux, dual-booting is the best of both worlds. You can switch between Windows for work or gaming and Arch Linux for coding, customization, and learning Linux deeply.

In this blog, I'll walk you through "" step-by-step "" how to safely install Arch Linux alongside Windows 10, covering BIOS/UEFI setup, partitioning, GRUB bootloader installation, and recovery tips. Let's make sure you don't lose your data in the process!

What You'll Need

Before we start, here's what you'll need ready:

• 👑’½ A USB drive (at least 4GB)
• 👑ªŸ Windows 10 already installed
• 👑Œ Internet connection
• 👑§  Basic command-line knowledge
• 👑"€ Arch Linux ISO "" Download from official site
• 👑§° A tool like Rufus or Balena Etcher (to make a bootable USB)

Step 1: Prepare Windows for Dual Boot

Backup your data "" Always first.

Disable Fast Startup & Hibernation:

powercfg /h off

Go to: Control Panel →’ Power Options →’ Choose what power buttons do →’ Uncheck "Turn on fast startup"

Shrink Windows Partition to make space for Arch:

1. Press Win + X →’ Disk Management
2. Right-click your main drive (C:)
3. Select Shrink Volume
4. Leave at least 40GB free for Arch Linux

You'll now have unallocated space "" don't format it! Arch installer will handle it.

Step 2: Create a Bootable Arch Linux USB

Use Rufus (on Windows):

• Select your USB drive
• Choose the Arch ISO file
• Set:
  • Partition scheme →’ GPT (for UEFI) or MBR (for BIOS)
  • File System →’ FAT32
• Click Start

Step 3: Boot Into Arch Linux Installer

1. Restart your PC
2. Enter BIOS/UEFI (press F2, Del, or Esc depending on your system)
3. Disable Secure Boot
4. Set your USB as the first boot device
5. Boot "" you'll see the Arch Linux live menu. Choose: Boot Arch Linux (x86_64)

Step 4: Check Internet Connection

For Ethernet (wired):

ping archlinux.org

If you see replies, you're good.

For Wi-Fi:

iwctl
device list
station wlan0 scan
station wlan0 get-networks
station wlan0 connect YourWiFiName
exit
ping archlinux.org

Step 5: Partition the Disk

Run:

lsblk

Find your drive (e.g., /dev/sda or /dev/nvme0n1).

We'll use cfdisk "" it's easy and safe.

cfdisk /dev/sda

Choose: GPT (if UEFI) or DOS/MBR (if BIOS)

Now create:

1. EFI partition (if UEFI):
   • Size: 512MB
   • Type: EFI System
2. Root partition (Linux):
   • Use the unallocated space you created earlier
   • Type: Linux filesystem
3. (Optional) Swap:
   • Size: 2—4GB
   • Type: Linux swap

Write changes →’ confirm →’ quit.

Step 6: Format Partitions

For UEFI systems:

mkfs.fat -F32 /dev/sda1

For the root partition:

mkfs.ext4 /dev/sda2

If you made a swap partition:

mkswap /dev/sda3
swapon /dev/sda3

Step 7: Mount the Partitions

mount /dev/sda2 /mnt
mkdir /mnt/boot
mount /dev/sda1 /mnt/boot

Step 8: Install Base System

pacstrap /mnt base linux linux-firmware vim networkmanager

Then generate fstab:

genfstab -U /mnt >> /mnt/etc/fstab

Step 9: Chroot Into the System

arch-chroot /mnt

Set timezone:

ln -sf /usr/share/zoneinfo/Asia/Karachi /etc/localtime
hwclock --systohc

Set locale:

echo "en_US.UTF-8 UTF-8" >> /etc/locale.gen
locale-gen
echo "LANG=en_US.UTF-8" > /etc/locale.conf

Set hostname:

echo "archpc" > /etc/hostname

Set root password:

passwd

Step 10: Install GRUB Bootloader

For UEFI systems:

pacman -S grub efibootmgr os-prober
grub-install --target=x86_64-efi --efi-directory=/boot --bootloader-id=Arch
os-prober
grub-mkconfig -o /boot/grub/grub.cfg

For Legacy BIOS systems:

pacman -S grub os-prober
grub-install /dev/sda
os-prober
grub-mkconfig -o /boot/grub/grub.cfg

✅ You'll see that GRUB detects your Windows Boot Manager automatically!

Step 11: Enable Network and Exit

systemctl enable NetworkManager
exit
umount -R /mnt
reboot

Remove the USB when prompted.

Step 12: Boot Menu (Choose OS)

On reboot, you'll see the GRUB menu:

• Arch Linux
• Windows Boot Manager

You can switch easily between both OSes whenever you boot.

Troubleshooting Tips

If GRUB doesn't show Windows:

sudo os-prober
sudo grub-mkconfig -o /boot/grub/grub.cfg

If booting directly into Windows:

Go into BIOS and ensure Arch/GRUB is first in the boot order.

If Arch doesn't boot:

1. Boot into live USB again
2. Mount root partition:

   mount /dev/sda2 /mnt
   arch-chroot /mnt
   grub-install /dev/sda
   grub-mkconfig -o /boot/grub/grub.cfg
   reboot


Bonus Tip: Keep Both OSes Clean

• Don't touch Windows partitions from Linux unless you know what you're doing.
• Keep Windows updates enabled.
• Use Timeshift in Linux for snapshots "" it can save you during a failed update.

Final Thoughts

Dual-booting Windows 10 and Arch Linux gives you the power to enjoy both ecosystems "" productivity in Windows, and full control in Linux. If you follow this guide carefully, you'll have a smooth dual-boot setup with zero data loss.
